Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR

A Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR support HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable and N+1 hot spare. This Uniview NVR has 1 channel, BNC Two-way Audio input. This NVR has 4 RJ-45 10M/ 100M/ 1000M adaptive Ethernet Interface and 2 1000M SFP Ethernet network interfaces, Rear panel 4 x USB3.0. This Uniview NVR516-64 has a Redundant power supply optional and supports 12V power output. This Uniview NVR516-64 has 2 slots decoding cards (4-ch HDMI or 6-ch HDMI outputs per card) for optional. It has 2 Unit chassis that easily mount a 19-inch rack. It has 16 SATA interfaces up to 8TB for each HDD and 1 eSATA interface. This NVR features RAID 1/ 5/ 6/ 10/ 50/ 60 disk array and has 4 x 12MP@20, 4 x 4K@30, 16 x 1080p@30, 36 x 720p@30, 64 x D1 decoding capability.

eSATA Interface

This Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR has 1 advanced eSATA interface. The eSATA connect outside a computer. eSATA combines the functionality of a USB port and source of power in a single connector.

miniSAS Ports

This Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR features SAS RAID ports. These ports offer a cost-effective balance of Video storage capacity and satisfy stringent data requirement availability.

Buy Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR from Star Tech

In Bangladesh, you can the get original Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR From Star Tech. We have a large collection of the latest Uniview NVR to purchase for your Security. Order Online Or Visit your Nearest Star Tech Shop to get yours at the lowest price. The Uniview NVR516-64 comes with a 2-year warranty.

What is the price of Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR in Bangladesh?

The latest price of Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR in Bangladesh is 0৳. You can buy the Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR at best price from our website or visit any of our showrooms.

System
Operating SystemLinux system
Audio and Video
IP Camera Input64 Channel
Two-Way Talk1-ch, BNC
Display
InterfaceVGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
HDMI1/HDMI2 (HDMI audio output is not supported): 4K (3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Decoding Capacity4 x 12MP@20, 4 x 4K@30, 16 x 1080p@30, 36 x 720p@30, 64 x D1
Recording
Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Video Detection And Alarm
Video DetectionIntrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Behavior Search, People Flow Counting, Crowd Density Monitoring
Alarm Input24 Channel
Relay Output8 Channel
Playback And Backup
Sync Playback64 Channel
Third Party Support
Third Party SupportONVIF conformance: Profile S, Profile G, Profile C, Profile Q, Profile A, Profile T
Network
Interface4 RJ45
Ethernet Port10M/100M/1000M adaptive Ethernet Interface
2 1000M SFP Ethernet Interface
Serial Interface: 1 x RS232, 1 x RS485
Maximum User AccessRemote Users: 128
Storage
Internal HDD16 SATA interfaces
HDD Modeup to 8TB for each HDD
eSATA1 eSATA interface
miniSAS: 2 miniSAS ports
Auxiliary Interface
USBRear panel: 4 x USB3.0
Power
Power Supply100 ~ 240V AC
Power Consumption≤ 50 W (without HDD)
Component Environment
Operational Conditions-10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing)
Construction
Dimensions482mm ×477mm × 131mm (18.8"× 19.0" ×5.1")
Net Weight≤ 10 Kg (22.05 lb)
Warranty
Manufacturing Warranty2 Year Warranty

2 Year Warranty
