A Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR support HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable and N+1 hot spare. This Uniview NVR has 1 channel, BNC Two-way Audio input. This NVR has 4 RJ-45 10M/ 100M/ 1000M adaptive Ethernet Interface and 2 1000M SFP Ethernet network interfaces, Rear panel 4 x USB3.0. This Uniview NVR516-64 has a Redundant power supply optional and supports 12V power output. This Uniview NVR516-64 has 2 slots decoding cards (4-ch HDMI or 6-ch HDMI outputs per card) for optional. It has 2 Unit chassis that easily mount a 19-inch rack. It has 16 SATA interfaces up to 8TB for each HDD and 1 eSATA interface. This NVR features RAID 1/ 5/ 6/ 10/ 50/ 60 disk array and has 4 x 12MP@20, 4 x 4K@30, 16 x 1080p@30, 36 x 720p@30, 64 x D1 decoding capability.
This Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR has 1 advanced eSATA interface. The eSATA connect outside a computer. eSATA combines the functionality of a USB port and source of power in a single connector.
This Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR features SAS RAID ports. These ports offer a cost-effective balance of Video storage capacity and satisfy stringent data requirement availability.
In Bangladesh, you can the get original Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR From Star Tech. We have a large collection of the latest Uniview NVR to purchase for your Security. Order Online Or Visit your Nearest Star Tech Shop to get yours at the lowest price. The Uniview NVR516-64 comes with a 2-year warranty.
The latest price of Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR in Bangladesh is 0৳. You can buy the Uniview NVR516-64 64 Channel 4K 16 HDDs RAID NVR at best price from our website or visit any of our showrooms.
System | ||
Operating System | Linux system | |
Audio and Video | ||
IP Camera Input | 64 Channel | |
Two-Way Talk | 1-ch, BNC | |
Display | ||
Interface | VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI1/HDMI2 (HDMI audio output is not supported): 4K (3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | |
Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
Decoding Capacity | 4 x 12MP@20, 4 x 4K@30, 16 x 1080p@30, 36 x 720p@30, 64 x D1 | |
Recording | ||
Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
Video Detection And Alarm | ||
Video Detection | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Behavior Search, People Flow Counting, Crowd Density Monitoring | |
Alarm Input | 24 Channel | |
Relay Output | 8 Channel | |
Playback And Backup | ||
Sync Playback | 64 Channel | |
Third Party Support | ||
Third Party Support | ONVIF conformance: Profile S, Profile G, Profile C, Profile Q, Profile A, Profile T | |
Network | ||
Interface | 4 RJ45 | |
Ethernet Port | 10M/100M/1000M adaptive Ethernet Interface 2 1000M SFP Ethernet Interface Serial Interface: 1 x RS232, 1 x RS485 | |
Maximum User Access | Remote Users: 128 | |
Storage | ||
Internal HDD | 16 SATA interfaces | |
HDD Mode | up to 8TB for each HDD | |
eSATA | 1 eSATA interface miniSAS: 2 miniSAS ports | |
Auxiliary Interface | ||
USB | Rear panel: 4 x USB3.0 | |
Power | ||
Power Supply | 100 ~ 240V AC | |
Power Consumption | ≤ 50 W (without HDD) | |
Component Environment | ||
Operational Conditions | -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing) | |
Construction | ||
Dimensions | 482mm ×477mm × 131mm (18.8"× 19.0" ×5.1") | |
Net Weight | ≤ 10 Kg (22.05 lb) | |
Warranty | ||
Manufacturing Warranty | 2 Year Warranty |
