Z-COM SP250-S5 is a professional directional Wi-Fi 6 outdoor access point for rural, wind power plant, solar power plant, ports, and camping long-distance CPE etc.
SP250-S5 with 11dBi internal high-gain antennas for PtP/PtMP deployment and power amplifier allows simultaneous transmission of up to 1.774Gbps, which fully comply with IEEE 802.11ax, OFDMA Modulation, MU-MIMO, and BSS Color Spatial Reuse, and supports up to 65% higher total throughput in Wi-Fi 5 environment. Equipped with a high-performance Qualcomm Chipset, the Z-COM SP250-S5 features the latest in rugged weatherproofing and Wi-Fi 6 technology with guaranteed performance and reliability in the harshest environments
Standards
| IEEE 802.11a/b/g/n/ac/ax |
Bandwidth
| 2.4GHz: 20/40 MHz 5GHz: 20/40/80 MHz |
Frequency Bands and Operating Channels
| Taiwan | 2.412 – 2.462 GHz; 11 channels 5.180 – 5.320 GHz; 8 channels 5.500 – 5.720 GHz ; 12 channels 5.745 – 5.825 GHz; 5 channels |
| US | 2.412 – 2.462 GHz; 11 channels 5.180 – 5.320 GHz; 8 channels 5.500 – 5.720 GHz ; 12 channels 5.745 – 5.825 GHz; 5 channels |
| EU | 2.412 – 2.472 GHz; 13 channels 5.180 – 5.320 GHz; 8 channels 5.500 – 5.700 GHz ; 11 channels |
| China | 2.412 – 2.472 GHz; 13 channels 5.180 – 5.320 GHz; 8 channels 5.745 – 5.825 GHz; 5 channels |
| Japan | 2.412 – 2.472 GHz; 13 channels 5.180 – 5.320 GHz; 8 channels 5.500 – 5.720 GHz; 12 channels |
| India | 2.412 – 2.472 GHz; 13 channels 5.180 – 5.320 GHz; 8 channels 5.500 – 5.720 GHz ; 12 channels 5.745 – 5.865 GHz; 7 channels |
| Note | *Operating Channel depends on configured regulatory domain. |
Ethernet
| 1 x 10/100/1000M/2.5Gbps WAN Port 1 x 10/100/1000M/2.5Gbps LAN Port |
Supported Wireless LAN Controllers
| -WS5G2 / WS7G2 /WS10G2 -zMEC (x86) |
IP Rating
| IP67 |
Environmental
| Storage | Temperature: -40 ~ 70 ℃ Humidity: 5 ~ 95% |
| Operating | Temperature: -40 ~ 65 ℃ Humidity: 5 ~ 95% (non-condensing) |
Compliance Standard
| IEC/EN 62368-1 EN55032 & EN55024 WEEE & RoHS IEEE standards: IEEE 802.11a/b/g/n/ac/ax IEEE 802.11d, e, h, i, j, k, r, u, v time stamp, w, and z standards Multimedia: Wi-Fi multimedia (WMM) Security: Open System 802.1x WPA-PSK/WPA-Enterprise WPA3-PSK/WPA3-Enterprise Extensible Authentication Protocol (EAP) types: EAP-Transport Layer Security (TLS) EAP-Tunneled TLS (TTLS) Protected EAP (PEAP) EAP-Subscriber Identity Module (SIM) *Above partial functions should be configured by Z-COM Wireless LAN Controllers (WLC) |
LED definition
| PWR：RED | Off: Power / system off On: Power / system on |
| WLAN：RED | Off: 5G and 2G WLAN interface disable On: 5G or 2G WLAN interface enable Blinking: Sending / receiving data |
| WAN：RED | Off: No Ethernet connection detected On: Ethernet connection detected Blinking: Sending / receiving data |
Radio Chains
| 2.4GHz | 2×2:2 |
| 5GHz | 2×2:2 |
Supported Data Rate
| 802.11axa: 4 to 1200 Mbps 802.11axg: 4 to 574 Mbps 802.11ac: 6.5 to 886 Mbps 802.11n: 6.5 to 300 Mbps 802.11a/g: 6 to 54 Mbps 802.11b: 1 to 11 Mbps |
EIRP
| 2.4GHz | 31dBm |
| 5GHz | 37dBm |
| Note | *The maximum power setting will vary by channel and according to individual country regulations. |
Min. Receive Sensitivity
| 2.4GHZ TX TARGET POWER (PER CHAIN)MU HE40 | MCS0：23dBm+/-2dBm MCS11：16dBm+/-2dBm |
| 2.4GHZ TX TARGET POWER (PER CHAIN)MU VHT40 | MCS9：20dBm+/-2dBm |
| 2.4GHZ RECEIVE SENSITIVITY HE20 | MCS0：<-96dBm MCS11：<-67dBm |
| 2.4GHZ RECEIVE SENSITIVITY HE40 | MCS0：<-93dBm MCS11：<-64dBm |
| 5GHZ TX TARGET POWER (PER CHAIN) MU HE40 | MCS0：23dBm+/-2dBm MCS11：15dBm+/-2dBm |
| 5GHZ TX TARGET POWER (PER CHAIN) MU VHT40 | MCS9：17dBm+/-2dBm |
| 5GHZ RECEIVE SENSITIVITY HE20 | MCS0：<-95dBm MCS11：<-67dBm |
| 5GHZ RECEIVE SENSITIVITY HE40 | MCS0：<-93dBm MCS11：<-64dBm |
| 5GHZ RECEIVE SENSITIVITY HE80 | MCS0：<-90dBm MCS11：<-59dBm |
Power
| Power Consumption | ≤ 25W |
| Power Supply | WAN Port：PoE+ Input (802.3at) LAN Port ：PoE Output (802.3af) |
Physical Characteristic
| Dimensions | 296 (L) × 92 (W) × 283 (H) mm |
| Weight | 1.87kg |
| Mounting Type | Pole |
Package Contents
| 1 x SP250-S5 1 x Mounting Bracket |
Optional Accessories
| SP-CBM5: Anti-theft Steel Rope Kit SP-MKM5: Two-dimensional Mounting Kit SP-WP-CM20: Waterproof Cable Gland SP-48063-XX: 48V/30W PoE Injector |
