Z-COM AS240 is mainstream and value Wi-Fi 6 indoor ceiling access point, which is ideal for retail, SOHO, clinic and other indoor applications.
It is affordable, small and easy to use, but at the same time comes with a very powerful Qualcomm Chipset, capable of all the advanced configurations and serve dual-band 5GHz and 2.4GHz radio at the same time.
| IEEE 802.11 a/b/g/n/ac/ax |
Physical Data Rates Supported Rates
| 802.11axa: 8.6 to 1200Mbps 802.11axg: 8.6 to 574Mbps 802.11ac: 6.5 to 867Mbps 802.11n : 6.5 to 300Mbps 802.11a/g: 6 to 54Mbps 802.11b: 1 to 11Mbps |
Frequency Bands and Operating Channels
| Taiwan | 2.412 – 2.462 GHz；11 channels 5.180 – 5.320 GHz；8 channels 5.500 – 5.720 GHz；12 channels 5.745 – 5.825 GHz；5 channels |
| US | 2.412 – 2.462 GHz；11 channels 5.180 – 5.320 GHz；8 channels 5.500 – 5.720 GHz；12 channels 5.745 – 5.825 GHz；5 channels |
| EU | 2.412 – 2.472 GHz；13 channels 5.180 – 5.320 GHz；8 channels 5.500 – 5.700 GHz；11 channels |
| China | 2.412 – 2.472 GHz；13 channels 5.180 – 5.320 GHz；8 channels 5.745 – 5.825 GHz；5 channels |
| Japan | 2.412 – 2.472 GHz；13 channels 5.180 – 5.320 GHz；8 channels 5.500 – 5.720 GHz；12 channels |
| India | 2.412 – 2.472 GHz；13 channels 5.180 – 5.320 GHz；8 channels 5.500 – 5.720 GHz；12 channels 5.745 – 5.865 GHz；7 channels |
| Notice | *Operating Channel depends on configured regulatory domain. |
RF
| Antenna Type | Internal |
| Antenna Gain (max) | 2.4GHz：2dBi 5GHz：2dBi |
| EIRP | 2.4GHz：20dBm 5GHz：20dBm |
| Frequency Bands | ISM (2.4-2.484GHz) U-NII-1 (5.15-5.25GHz) U-NII-2A (5.25-5.35GHz) U-NII-2C (5.47-5.725GHz) U-NII-3 (5.725-5.85GHz) |
PERFORMANCE TABLE
| 2.4GHz TX TARGET POWER (PER CHAIN) | MU HE40 MCS0 : 15dBm±2dBm MCS11 : 8dBm±2dBm MU VHT40 MCS9 : 10dBm±2dBm |
| 5GHz TX TARGET POWER (PER CHAIN) | MU HE40 MCS0 : 15dBm±2dBm MCS11 : 8dBm±2dBm MU VHT40 MCS9 : 10dBm±2dBm |
| 2.4GHz RECEIVE SENSITIVITY | HE20 MCS0 : <-89dBm MCS11 : <-60dBm HE40 MCS0 : <-87dBm MCS11 : <-59dBm |
| 5GHz RECEIVE SENSITIVITY | HE20 MCS0 : <-94dBm MCS11 : <-65dBm HE40 MCS0 : <-91dBm MCS11 : <-62dBm HE80 MCS0 : <-88dBm MCS11 : <-59dBm |
STANDARDS
| Compliance Standards | FCC Part 15 (Class B) FCC Part 15C FCC Part 15E NCC WEEE & RoHS IEEE standards： IEEE 802.11a/b/g/n/ac/ax |
Radio Chains
| 2.4GHz | 2×2:2 |
| 5GHz | 2×2:2 |
Bandwidth Channelization
| 2.4GHz | 2.4GHz：20/40 MHz |
| 5GHz | 20/40/80 MHz |
MIMO
| MU-MIMO |
PERFORMANCE AND CAPACITY
| Peak PHY Rates | 2.4 GHz：574 Mbps 5 GHz：1200 Mbps |
| Client Capacity | 1024 |
INTERFACE
| Ethernet | 1x 10/100/1000Mbps WAN Port 1x 10/100/1000Mbps LAN Port |
| Addition | 1x Reset Button |
| Environmental | Storage Temperature：-40~ 70 ℃ Humidity：5 ~ 95% Operating Temperature：-15 ~ 55 ℃ Humidity：5 ~ 95% (non-condensing) |
MECHANICAL
| Mounting Method | Ceiling |
| Dimension | 175 mm × 39.1 mm |
| Anti-static Grade | IEC61000-4-2(Criteria B) Air：±8kV Contact：±4kV |
| Green | RoHS compliant |
| LED Definition | PWR/SYS：Green Green Off：power / system off Green On：power / system on WLAN ：Green Off：No WLAN connection detected Green On：WLAN connection detected Green Blinking：Sending / receiving data WAN：Green Off：No Ethernet connection detected Green On：Ethernet connection detected Green Blinking：Sending / receiving data |
| Supported WLC or container-base | - WS5G2 / WS7G2 /WS10G2 / WS200G2 / WS500G2 / WS1000G2 - zMEC |
| Warranty | 1 year |
