The SP230 series high integrated, outdoor 802.11ac Wave2 wireless access point delivers exceptional performance. It supports a wireless transmission rate up to 1167 Mbps.
Designed for extreme temperatures and environments and include IP67 waterproof and dust resistance that can withstand harsh environments. The SP230 Series is equipped with a PoE out capability that enables cost-effective deployment to smart surveillance applications. Especially, the SP230-S5 features high antenna gain which supports over 6Km data transmission.
The added benefit of the Mesh and Bluetooth location services greatly improves promotion and management efficiency.
The SP230 series is specifically suitable for developing countries and remote areas. It not only provides users with long-range and stable signal transmission for easy and quick deployment, but also solves the problem of labor shortage for equipment maintenance, speeding up network penetration.
Standards
| IEEE 802.11a/b/g/n/ac |
Bandwidth
| 20 / 40 / 80 MHz |
Frequency Bands
| 2.4GHz | US: 2.412 – 2.462GHz EU: 2.412 – 2.472GHz Japan: 2.412 – 2.472GHz China: 2.412 – 2.472GHz India: 2.412 – 2.472GHz |
| 5GHz | US: 5.15GHz – 5.35GHz 5.47GHz – 5.85GHz EU: 5.15GHz – 5.35GHz 5.47GHz – 5.725GHz Japan: 5.15GHz – 5.35GHz 5.47GHz – 5.725GHz China: 5.15GHz – 5.35GHz 5.725GHz – 5.85GHz India: 5.15GHz – 5.35GHz 5.725GHz – 5.85GHz 5.85GHz – 5.875GHz |
Max. Transmit Power
| 2.4GHz | SP230 2.4GHz: 35dBm w/ 2 ant. SP230-S5 2.4GHz: 35dBm w/ 2 ant. |
| 5GHz | SP230 5GHz: 32dBm w/ 2 ant. SP230-S5 5GHz: 38dBm w/ 2 ant. |
| Notice | *The maximum power setting will vary by channel and according to individual country regulations. |
Interfaces
| 2 × 10/100/1000 BASE-T 1 WAN port support 802.3at PoE 1 LAN port support PoE Out (Max 13Watt, 45+/78-) 1 × Ground terminal |
Indicator
| Power / System / WLAN / WAN |
Power
| Power Consumption | < 12W |
| Power Input | DC 48V, 0.5A PoE |
Physical Characteristics
| Dimensions | 151 (L) × 75.5 (W) × 235 (H) mm |
| Weight | 1kg |
| Mounting type | Pole mount |
Bluetooth
| Version | 4.1 |
| Frequency | 2400 – 2480MHz |
| Antenna | 1.5dBi (Embedded) |
Radio Chains
| 2.4GHz | 2x2:2 |
| 5GHz | 2x2:2 |
Supported Data Rates
| 802.11b: 11 Mbps 802.11a/g: 54 Mbps 802.11n: 300Mbps 802.11ac: 867Mbps |
Operating Channels
| 2.4GHz | US: 1 – 11 EU: 1 – 13 Japan: 1 – 13 China: 1 – 13 India: 1 – 13 |
| 5GHz | US: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140, 149, 153, 157, 161, 165 EU: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140 Japan: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140 China: 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 India: 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165, 169, 173 |
Antenna Peak Gain
| SP230 | 2.4GHz: 5dBi (Embedded) 5GHz: 5dBi (Embedded) |
| SP230-S5 | 2.4GHz: 5dBi (Embedded) 5GHz: 11dBi (Embedded) |
Min. Receive Sensitivity
| -99dBm |
Supported Wireless LAN Controllers
| WS5G2 / WS7G2 /WS10G2 |
IP Rating
| IP67 |
Environmental
| Storage | Temperature: -40 – 80 ℃ Humidity: 10 – 90% |
| Operating | Temperature: -40 – 70 ℃ Humidity: 10 – 90% (non-condensing) |
Compliance Standards
| IEC/EN 60950 EN55032 & EN55024 WEEE & RoHS Radio approvals: EN 300 328, EN301 893 (Europe) EN 301 489-1 and -17 (Europe) FCC NCC SRRC (China) IEEE standards: IEEE 802.11a/b/g/n/ac IEEE 802.11d, e, h, i, j, k, r, u, v time stamp, w, and z standards Multimedia: Wi-Fi multimedia (WMM) Security: Open System 802.1x WPA-PSK/WPA2-PSK WPA-Enterprise/WPA2-Enterprise Extensible Authentication Protocol (EAP) types: EAP-Transport Layer Security (TLS) EAP-Tunneled TLS (TTLS) Protected EAP (PEAP) EAP-Subscriber Identity Module (SIM) *Above partial functions should be configured by Z-COM Wireless LAN Controllers (WLC) |
