Dahua XVR1B16-I 16-Channel Penta-brid Compact Digital Video Recorder

The Dahua XVR1B16-I is a stand-alone recorder that captures HDMI videos as you watch them, without the need for a PC. Be it your games or sports games, Dahua DH-XVR1B16-I records HDMI video at the press of a button, or on a schedule, even when your TV is powered off. With the remote control, view the recorded videos at your leisure. The snapshot function lets you capture your favorite moments into inspiring high-quality pictures. Dahua DH-XVR1B16-I makes post-production easy as well. The built-in video editor allows you to trim and merge clips seamlessly without a PC. Knowing you'll have the final touch just makes recording so much easier. The Dahua XVR1B16-I comes with a 1-year warranty.

What is the price of DAHUA XVR1B16-I Digital Video Recorder in Bangladesh?

The latest price of DAHUA XVR1B16-I Digital Video Recorder in Bangladesh is 6,850৳. You can buy the DAHUA XVR1B16-I Digital Video Recorder at best price from our website or visit any of our showrooms.

Download

System
Main Processor Embedded processor
Operating System Embedded linux
Audio and Video
IP Camera Input 16+2 channels, each channel up to 6MP
Two-Way Talk Reuse audio in/out, RCA
Display
Interface 1 HDMI; 1 VGA
Resolution 1920 × 1080, 1280 × 1024, 1280 × 720
Multi-Screen Display When IP extension mode not enabled: 1/4/8/9/16
When IP extension mode enabled: 1/4/8/9/16
OSD Camera title; Time; Video loss; Camera lock; Motion detection; Recording
Recording
Compression AI Coding/H.265+/H.265/H.264+/H.264
Resolution 1080N; 720p; 960H; D1; HD1; BCIF; CIF; QCIF
Record Rate Main Stream:
the 1st channel 1080N/720p (1 fps–25/30 fps), others 1080N/720p (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps)

Sub stream:
CIF/QCIF (1 fps–7 fps)
Bit Rate 32 kbps–4096 kbps per channel
Record Mode Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop
Record Interval 1 min–60 min (default: 60 min), Pre-record: 1 sec–30 sec, Post-record: 10 sec–300 sec
Video Detection And Alarm
Trigger Event Recording; PTZ; Tour; Video Push; Email; FTP; Snapshot; Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
Alarm Input N/A
Relay Output N/A
Playback And Backup
Sync Playback 1/4/9/16
Search Mode Time/Date, Alarm, MD and Exact Search (accurate to second)
Playback Function Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom
Backup Mode USB Device/Network
Third Party Support
Third Party Support Dahua, Arecont Vision, AXIS; Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Network
Interface 1 RJ-45 Port (100 MB)
Network Function HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Maximum User Access 128 users
Smart Phone iPhone; iPad; Android
Interoperability ONVIF 16.12, CGI Conformant
Storage
Internal HDD 1 SATA port, up to 6 TB capacity
eSATA N/A
Auxiliary Interface
USB 2 USB ports (USB 2.0)
RS232 N/A
RS485 N/A
Power
Power Supply DC 12V/2A
Power Consumption < 10W
Component Environment
Operational Conditions -10°C to +45°C (+14°F to +113°F), 10%–90% (RH)
Storage Conditions -20°C to +70°C (-4°F to +158°F), 0%–90% (RH)
Construction
Dimensions Compact 1U, 260.0 mm × 231.4 mm × 47.6 mm
(10.24'' × 9.11'' × 1.87'')
Net Weight 0.89 kg (1.96 lb)
Gross Weight 1.42 kg (3.13 lb)

System
Main Processor	Embedded processor
Operating System	Embedded linux
IP Camera Input	16+2 channels, each channel up to 6MP
Two-Way Talk	Reuse audio in/out, RCA
Interface	1 HDMI; 1 VGA
Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Multi-Screen Display	When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16
OSD	Camera title; Time; Video loss; Camera lock; Motion detection; Recording
Compression	AI Coding/H.265+/H.265/H.264+/H.264
Resolution	1080N; 720p; 960H; D1; HD1; BCIF; CIF; QCIF
Record Rate	Main Stream: the 1st channel 1080N/720p (1 fps–25/30 fps), others 1080N/720p (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps) Sub stream: CIF/QCIF (1 fps–7 fps)
Bit Rate	32 kbps–4096 kbps per channel
Record Mode	Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop
Record Interval	1 min–60 min (default: 60 min), Pre-record: 1 sec–30 sec, Post-record: 10 sec–300 sec
Trigger Event	Recording; PTZ; Tour; Video Push; Email; FTP; Snapshot; Buzzer and Screen Tips
Video Detection	Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
Alarm Input	N/A
Relay Output	N/A
Sync Playback	1/4/9/16
Search Mode	Time/Date, Alarm, MD and Exact Search (accurate to second)
Playback Function	Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom
Backup Mode	USB Device/Network
Third Party Support	Dahua, Arecont Vision, AXIS; Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Interface	1 RJ-45 Port (100 MB)
Network Function	HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Maximum User Access	128 users
Smart Phone	iPhone; iPad; Android
Interoperability	ONVIF 16.12, CGI Conformant
Internal HDD	1 SATA port, up to 6 TB capacity
eSATA	N/A
USB	2 USB ports (USB 2.0)
RS232	N/A
RS485	N/A
Power Supply	DC 12V/2A
Power Consumption	< 10W
Operational Conditions	-10°C to +45°C (+14°F to +113°F), 10%–90% (RH)
Storage Conditions	-20°C to +70°C (-4°F to +158°F), 0%–90% (RH)
Dimensions	Compact 1U, 260.0 mm × 231.4 mm × 47.6 mm (10.24'' × 9.11'' × 1.87'')
Net Weight	0.89 kg (1.96 lb)
Gross Weight	1.42 kg (3.13 lb)
