TP-Link CPE605 5GHz 150Mbps 23dBi Outdoor CPE:
With a 23dBi high-gain directional Cassegrain antenna and dedicated metal reflector, the CPE605 provides excellent beam directivity, improved latency, and noise immunity.
HARDWARE FEATURES | |
---|---|
PROCESSOR | Qualcomm 560MHz CPU, MIPS 74Kc |
MEMORY | 64MB DDR2 RAM,8MB Flash |
INTERFACE | 1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button |
POWER SUPPLY | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC |
DIMENSIONS ( W X D X H ) | 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.) |
ANTENNA GAIN | 23dBi |
ANTENNA BEAMWIDTH | 7°(Azimuth), 10°(Elevation) |
PROTECTION | 15KV ESD Protection 6KV Lightning Protection |
ENCLOSURE | Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dustproof design |
WIRELESS FEATURES | |
---|---|
WIRELESS STANDARDS | IEEE 802.11a/n |
PROPRIETARY PROTOCOL | TDMA Mode (with Pharos MAXtream enabled) |
WIRELESS SPEEDS | Up to 150Mbps (40MHz,Dynamic) Up to 72.2Mbps (20MHz,Dynamic) Up to 36.1Mbps (10MHz,Dynamic) Up to 18.05Mbps (5MHz,Dynamic) |
FREQUENCY | 5.15~5.85GHz |
TRANSMIT POWER | Max. 23dBm (Adjustable power by 1dBm) |
TP-Link CPE605 5GHz 150Mbps 23dBi Outdoor CPE:
With a 23dBi high-gain directional Cassegrain antenna and dedicated metal reflector, the CPE605 provides excellent beam directivity, improved latency, and noise immunity.
1-Year Warranty
